3000W Pure Sine Wave Power Inverter 12V/24V/48V to 110-240V AC

3000W Pure Sine Wave Power Inverter 12V/24V/48V to 110-240V AC

Tên thương hiệu: SZSSTH/OEM
Số mẫu: MTS
MOQ: 2 mảnh
giá bán: USD$151/pieces 2-99 pieces
Thông tin chi tiết
Nguồn gốc:
Quảng Đông, Trung Quốc
Mạng:
SDK
Kiểu:
Bộ biến tần DC/AC
Loại đầu ra:
Hai
Đầu ra hiện tại:
Trọng tải
Tần số đầu ra:
50Hz/60Hz
Kích cỡ:
514*229*110MM
Cân nặng:
8,5kg
Dạng sóng đầu ra:
Sóng hình sin
Sức mạnh định mức:
3000W
Đỉnh công suất:
6000W
Tính thường xuyên:
50/60 Hz
Điện áp đầu vào:
DC 12V(10.4-14.8V)/24V20-28V)/48V
Điện áp đầu ra:
110V/220V /230V /240V
Đầu ra USB:
5V 2.4A
Sức mạnh sẵn có:
93%
Đầu ra loại C:
PD20W
Bảo hành:
12 tháng
Hỗ trợ tùy chỉnh:
tái cấu trúc phần mềm
Làm nổi bật:

3000W pure sine wave inverter

,

12V to 240V power inverter

,

48V pure sine inverter

Mô tả sản phẩm
3000 W Pure Sine Wave Power Inverter – DC 12V/24V/48V to AC 110–240V (Model MTS 3000W)
Product Specifications
Network SDK
Type DC/AC Inverters
Output Type DUAL
Output Current Load
Output Frequency 50Hz/60Hz
Size 514*229*110MM
Weight 8.5KG
Output waveform Pure Sine Wave
Rated power 3000W
Peak power 6000W
Input voltage DC 12V(10.4-14.8V)/24V20-28V)/48V
Output voltage 110V/220V /230V /240V
USB output 5V 2.4A
Availability power 93%
Type-C output PD20W
Warranty 12 Months
Customized support Software reengineering
Product Overview

Upgrade your energy setup with the 3000 W Pure Sine Wave Power Inverter — the reliable and efficient solution for delivering clean, grid-quality AC power from DC sources. Engineered by Shenzhen Sheng Shi Tian He Electronic Technology Co., Ltd., this powerhouse inverter is perfect for homes, off-grid solar systems, RVs, and emergency backup applications.

3000W Pure Sine Wave Power Inverter 12V/24V/48V to 110-240V AC 0 3000W Pure Sine Wave Power Inverter 12V/24V/48V to 110-240V AC 1 3000W Pure Sine Wave Power Inverter 12V/24V/48V to 110-240V AC 2
Model Comparison
Model No. MTS-1000W MTS-2000W MTS-3000W MTS-4000W MTS-5000W MTS-6000W
Rated Power 1000W 2000W 3000W 4000W 5000W 6000W
Peak Power 2000W 4000W 6000W 8000W 10000W 12000W
Input voltage DC 12V(10.4-14.8V)/24V20-28V)/48V
Output voltage 110V/220V /230V /240V
Waveform Pure sine wave
Frequency 50Hz /60Hz+4Hz
Availability power 90.50%
Type-C output PD20W
USB output 5V 2.4A
Socket One AC Socket Dual AC Socket (EU, USA,Universal, Brazil socket optional)
Remote control 3W remote line control /5iw remote control
Cooling fan Yes
Low voltage alarm 10.5V+0.5V /20.5V+0.5V
Low voltage range 9.6V/20.5V
High voltage range >14.8V /31V
Non-load current 5.04A
Overload protection >1100W >2100W >3100W >4100W >5100W >6100W
Reverse protection Yes
Short-circuit protection Yes
Dimension 348*185*95MM 398*229*110MM 514.8*229*110MM 545*229*110MM 545*229*110MM 545*229*110MM
Warranty 1 Year
Key Features & Specifications
  • Pure Sine Wave Output: Produces high-quality utility-grade AC electricity, ensuring safe operation for sensitive electronics and appliances.
  • Versatile Input Voltage Support: Compatible with DC 12V (10.4 -14.8V), 24V (20-28V), and 48V battery systems, offering installation flexibility.
  • Full-Sized Power Capacity: Delivers a continuous 3000 W of clean power, with a robust peak surge capacity up to 6000 W—ideal for powering heavy-duty appliances like pumps and refrigerators.
  • Switchable AC Output Voltage: Supports 110V, 220V, 230V, and 240V voltages to accommodate different regional standards.
  • Multi-Region Frequency: Operates at both 50Hz and 60Hz, suitable for global use.
  • Convenient Device Charging: Includes a 5V/2.1A USB port and a Type-C PD20W output—perfect for charging smartphones, tablets, and other USB devices.
  • Reliable Efficiency: Converts DC to AC at approximately 90.5% efficiency, maximizing battery power and reducing losses.
  • Compact & Lightweight: At just 8.5 kg and measuring 514*229*110 mm, this inverter is highly portable and easy to install.
  • Warranty & Assurance: Comes with a 12-month warranty for dependable performance and support.
Packaging & Logistics
  • Single-Unit Packaging: Each inverter ships in a 47 × 22 × 9.2 cm box, with a gross weight of approximately 8.5 kg.
  • Lead Time: Approximately 15 days for orders of 1-10 units; pricing and delivery for larger orders are negotiable.
  • Customization (OEM/ODM): Available with custom logo, packaging, and graphics (minimum 300 units).
Why Choose This Inverter?
  • Pure Sine Wave Output ensures compatibility with sensitive devices—no buzzing, overheating, or interference.
  • High Continuous & Surge Power lets you power high-demand appliances, even during startup.
  • Broad Input Flexibility allows seamless integration with a variety of battery configurations.
  • Portable & Efficient Design makes it ideal for both stationary and mobile power applications.
  • Built-in Charging Ports provide added convenience for powering USB-enabled gadgets.
  • Trustworthy Manufacturer & Warranty offer peace of mind and professional support.
